Blue Sea DC MINI Battery Switch
Note: 6005 replaces 9005
Ignition protectedâsafe for installation aboard gasoline powered boats
Case design allows surface, front panel, or rear panel mounting
Isolating cover with snap-on sections protects rear contacts
Cranking Rating: 10 sec. |
1,500 Amps |
Intermittent Rating: 5 min. |
500 Amps |
Continuous Rating |
300 Amps |
Maximum Voltage Rating |
48 Volts DC |
Terminal Stud Size |
3/8"-16 (M10) |
Terminal Stud Torque |
120 in-lb (13.56 N m) max. |
Mounting Holes |
Accept #10 Screw |
Cable Size to Meet Ratings |
4/0 AWG (95mm ) |
Cable Clearance For 4/0 AWG Cables |
1.12" (28.4mm) |
Weight Lb (Kg) |
0.62 (0.28) |
