Home » MASTERVOLT » MASTERVOLT BATTERY CHARGERS » 24/20-3 MASTERVOLT CHARGEMASTER plus BATTERY CHARGER 24V
24/20-3 MASTERVOLT CHARGEMASTER plus BATTERY CHARGER 24V

24/20-3 MASTERVOLT CHARGEMASTER plus BATTERY CHARGER 24V

MASTERVOLT CHARGEMASTER PLUS


General specifications
Nominal output voltage 24 V
Max. output current primary output 20 A
Total charge current 20 A bij 28,5 V
Max. AC current (230 V / 120 V) 2,8 A / 5,6 A
Number of battery outlets 3 (max.)
Battery bank size 80-200 Ah
Nominal input voltage 120/240 V (80-275 V) 50/60 Hz
Galvanic isolation ja
Display/read-out LED display
Dimensions, hxwxd 291 x 210 x 105 mm
11.5 x 8.3 x 4.1 inch
Weight 2.5 kg
5.5 lb
Compliance CE, CEC, DOE, ABYC, UL1236, cULus, SAE J1171, ISO 8846, ACMA

Our price (Ex VAT) £410.78

PART NUMBER M44320205
Ask a question about this product

Description



FOR DATA SHEET PLEASE CLICK LINK BELOW:

24/20-3 CHARGEMASTER PLUS
